Texas Equipment Emporium · Aftermarket replacement
Water Pump for Toyota - OEM 16120-78151-71
$94.49List $160.25Save 41%
Available to order
Not sure it fits?
Call 817-600-5042 with your truck's model and serial number, or send a request.
Compatibility
Match the model on your truck's data plate, or the OEM number on your old part.
Toyota
62 modelsOEM 16120-78151-71
6FGU306FGCU156FGCU186FGCU206FGCU256FGCU306FGU156FGU186FGU206FGU255FG305FGU305FG105FG145FG155FG185FGU105FGU155FGU185FGU205FGU256FG236FG255FG286FG305FG205FG235FG255FGC105FGC135FGC155FGCU105FGCU135FGCU156FG106FG146FG156FG186FG205FGF306FG286FGA306FGF305FGF205FGC185FGC206FGA206FGA255FGC235FGC255FGCU185FGCU205FGCU256FGF156FGF185FGCU305FGF155FGF186FGF206FGF255FGC285FGC30
No matching model listed. Call 817-600-5042 and we'll check fitment for your truck.
Specifications
| Part number | TY16120-78151-71 |
| OEM cross-reference | 16120-78151-71 |
| Sort waterpump | flange |
| Type waterpump | A1 |
| Total height H1 (mm) | 112.3 |
| Maximum length L1 (mm) | 95.5 |
| Shaft diameter D1 (mm) | 15.9 |
| Neck diameter D2 (mm) | 28.4 |
| Flange/gear or pully diameter D3 (mm) | 68 |
| Total number of mounting holes in the flange (holes + thread) | 4 |
| Number of threads | 4 |
| Biggest thread TA1 | M8 |
| Metric pitch Pm1 (mm) | 1.25 |
| Smallest centre distance of nearest mounting holes C1 (mm) | 36 |
| Biggest centre distance of nearest mounting holes C2 (mm) | 36 |
| Gasket included | Yes |
| Weight (lbs) | 2.28 |
Details
Water Pump for Toyota forklifts. Aftermarket replacement for OEM part number 16120-78151-71.
Aftermarket replacement part. Brand names and OEM part numbers are used for reference only.
