Texas Equipment Emporium · Aftermarket replacement
Brake Wheel Cylinder for Toyota - OEM 47410-U2100-71
$38.43
Available to order
Not sure it fits?
Call 817-600-5042 with your truck's model and serial number, or send a request.
Compatibility
Match the model on your truck's data plate, or the OEM number on your old part.
Toyota
14 modelsOEM 47410-U2100-71
6FD206FD236FD256FD286FD306FDU206FDU256FGU306FGU206FGU256FG306FG236FG256FG20
No matching model listed. Call 817-600-5042 and we'll check fitment for your truck.
Specifications
| Part number | TY47410-U2100-71 |
| OEM cross-reference | 47410-U2100-71 |
| Bore diameter D1 (inch) | 1 1/8 |
| Bore diameter D1-mm (mm) | 28.58 |
| Number Fixation Holes | 2 |
| Length L (mm) | 77.9 |
| Neck Diameter D2 (mm) | 30 |
| Neck Height L1 (mm) | 12 |
| Thread size | M10 |
| Metric Pitch Pm1 (mm) | 1 |
| Inlet with Taper | Yes |
| Thread size TA2 (smallest) | M8 |
| Metric Pitch Pm2 (mm) | 1.25 |
| Smallest centre distance C1 (mm) | 44 |
| Type of wheel cylinder (RH / LH / neutral) | right |
| Pin type | type AK |
| Type of Oil | brake fluid |
| Weight (lbs) | 1.72 |
Details
Brake Wheel Cylinder for Toyota forklifts. Aftermarket replacement for OEM part number 47410-U2100-71.
Aftermarket replacement part. Brand names and OEM part numbers are used for reference only.
