Texas Equipment Emporium · Aftermarket replacement
Brake Wheel Cylinder for Toyota - OEM 47510-30414-71
$94.74
Available to order
Not sure it fits?
Call 817-600-5042 with your truck's model and serial number, or send a request.
Compatibility
Match the model on your truck's data plate, or the OEM number on your old part.
Toyota
9 modelsOEM 47510-30414-71
2FBCA202FBCA25TD20TD25FB35FB40TG20TG25FBCA30
No matching model listed. Call 817-600-5042 and we'll check fitment for your truck.
Specifications
| Part number | TY47510-30414-71 |
| OEM cross-reference | 47510-30414-71 |
| Bore diameter D1 (inch) | 1 1/4 |
| Bore diameter D1-mm (mm) | 31.75 |
| Number Fixation Holes | 4 |
| Length L (mm) | 108 |
| Neck Diameter D2 (mm) | 36 |
| Neck Height L1 (mm) | 10 |
| Thread size | M10 |
| Metric Pitch Pm1 (mm) | 1 |
| Inlet with Taper | Yes |
| Thread size TA2 (smallest) | M10 |
| Metric Pitch Pm2 (mm) | 1.25 |
| Thread size TA3 (largest) | M12 |
| Metric Pitch Pm3 (mm) | 1.25 |
| Smallest centre distance C1 (mm) | 43 |
| Largest centre distance C2 (mm) | 71 |
| Type of wheel cylinder (RH / LH / neutral) | left |
| Type of Oil | brake fluid |
| Weight (lbs) | 4.38 |
Details
Brake Wheel Cylinder for Toyota forklifts. Aftermarket replacement for OEM part number 47510-30414-71.
Aftermarket replacement part. Brand names and OEM part numbers are used for reference only.
